Export a diagram to an WebP image

  1. Open the draw.io menu and click Export As > WebP.
  2. Change the export settings to suit your requirements.
    • Choose the Zoom factor, set a Border width around your diagram.
    • If you only want to export the shapes and connectors that are currently selected, enable the Selection only checkbox. This only appears if you have selected part of your diagram.
    • Select whether to print the entire Diagram (default) or just a single diagram Page from the Size drop down list.
    • If you are diagramming in dark mode, change the Appearance to Dark.
    • Enable the checkboxes if you want a Shadow on your shapes, or to include the Grid of the drawing canvas.
      Choose the export settings for the WebP image
  3. Click Export and select the location to save your WebP file.
